USB-C 90 Degree Panel Mount Extension Cable | Male to Female 1ft (TBS-00321)

Mount a USB-C port where you can actually reach it. This panel mount extension takes a USB-C connection buried behind a dash, kick panel or ECU cover and brings it out to a flat surface you can plug into without pulling trim.

Why It Matters

Nexus ECUs tune over USB-C. If the unit lives behind a panel or under a seat, every laptop session starts with disassembly. A mounted port ends that. The receptacle takes the cable out the side at 90 degrees rather than straight back, so the whole assembly sits shallow behind the panel and the wire does not need clearance directly behind the port.

The Details

• SKU: TBS-00321
• USB 2.0, Type-C male to Type-C female
• Straight male plug, 90 degree side exit at the panel mount receptacle
• Two-hole mounting flange, no soldering required
• 480 Mbps data transfer
• Rated 20V / 3A
• 6 core 22/28AWG copper conductors, foil and braid double shielded
• PVC jacket
• Length: 1 ft (30 cm)

Kit Includes

• One USB-C 2.0 panel mount extension cable
• Panel mount screws

Applications

• Universal. Fits any vehicle or enclosure with room for a 30cm run and a flat mounting surface.

This is USB 2.0. It is intended for tuning, charging and general device connections, not high bandwidth video or storage.

Tuned By Shawn is a Platinum Haltech Dealer with in-house wiring and remote tuning services. Questions on where to mount it or how it fits your build, send them through before ordering.
