Radium Pump Electrical, Check Valves and Adapters | Universal (17-0048 / 20-0151 / 20-1009 / 20-0596 / 20-0798 / 13-1187)

Electrical hardware and check valves for in-tank pump installations.

A group of Radium Engineering electrical and check valve components used across fuel pump hanger and surge tank installations.

Choose Your Part

• Electrical bulkhead stud kit, 6 pack (17-0048)
• Fuel collection check valve (20-0151)
• Hose end 24AN 75 degree with wrench (20-1009)
• Early model fuel level adapter, 350Z / G35 (20-0596)
• Pump outlet adapter check valve, 10mm barb (20-0798)
• Triple pump base, 12mm inlet, brushless pumps (13-1187)

Features

• Hermetically sealed bulkhead studs in a 6 pack
• Check valves in collection and pump outlet configurations
• Triple pump base sized for 12mm inlet brushless pumps
• Anodized aluminum and stainless construction

The Details

The 20-0798 pump outlet check valve is the part Radium specifies for second pump positions on hangers where the chosen pump has no integrated check valve, notably the Walbro F90000295 and Ti Automotive E5LM. Without it those pumps can back-feed.

The 13-1187 triple pump base is the brushless variant with a 12mm inlet, distinct from the standard and reverse triple pump blocks stocked separately.

The 20-0596 fuel level adapter is early model specific for the 350Z and G35, addressing the sender differences between early and later cars.

Kit Includes

• Selected component with its sealing or mounting hardware

Applications

• Radium fuel pump hangers, surge tanks, and in-tank assemblies
• 20-0596: early model Nissan 350Z and Infiniti G35

Important Notes

• Confirm your pump lacks an integrated check valve before adding the 20-0798
• The 13-1187 base is for brushless pumps with a 12mm inlet
