Radium FCST Lift Pump Mounts All Depths | Universal (20-0214)

The older FCST units need their own bracket, and it reaches deeper than anything in the FCST-X range.

The Radium Engineering FCST lift pump mounts, all depths are laser cut polished stainless brackets for the original FCST platform, adding 8 inches (203mm) over the standard mounts supplied with those units. They place the lift pump correctly in cells up to 17 inches (432mm) deep, which is the deepest reach in Radium's lift pump mount range.

Features

• Two laser cut polished stainless steel brackets
• Adds 8in (203mm) over the standard FCST mounts
• Suits fuel cell depths up to 17in (432mm)
• Cut to length for a specific cell depth

The Details

These are platform specific and not interchangeable with the FCST-X range. They fit the 20-014X-XX, 20-049X-XX, 20-069X-XX, and 20-099X-XX FCST series only, several of which Radium has since discontinued, so this is often a service part for an existing installation rather than a new build purchase. Trim with a band saw or cut-off wheel to match your cell, and plan for longer hose and wiring once the pump sits lower. Note that FCST kits include the two brackets only, without the zip ties supplied in FCST-X kits.

Compatible FCST Models

• 20-014X-XX, 20-049X-XX, 20-069X-XX, and 20-099X-XX series

Important Notes

• Not compatible with any FCST-X unit; those use the 20-1212 through 20-1216 mounts
• Longer hose and wiring may be required
