Haltech Elite 1000/1500 Honda OBD-I B-Series Plug 'n' Play Adaptor Harness (HT-140840), from Tuned By Shawn
Plug-In Fitment
Plug-In Fitment

No wiring needed

Component Only
Component Only

No ECU included

Vendor:Haltech

Elite 1000/1500 Honda OBD-I B-Series Plug 'n' Play Adaptor Harness (HT-140840)

SKU: HT-140840

$495.00
Plug-In Fitment
Plug-In Fitment

No wiring needed

Component Only
Component Only

No ECU included
From Shawn: Not sure this product is right for your build? Email me at service@tunedbyshawn.com before you order. I answer these myself.

ECUs always ship FREE with Tuned By Shawn!

Manufacturer Limited Warranty

Product details

Description

Put a Haltech Elite 1000/1500 in an OBD-I Honda without cutting a single factory wire.

The Haltech Elite 1000/1500 Honda OBD-I B-Series Plug 'n' Play Adaptor Harness sits between the factory engine harness and a Haltech Elite 1000/1500 ECU. One side carries the factory ECU connectors, the other plugs straight into the Elite, so the factory loom stays untouched and the swap is fully reversible. A typical install is a few hours, not a weekend of pinouts and splices. It suits OBD-I B-series Hondas: 1992-1995 Civic, Integra and Prelude, and 1990-1995 Accord, with a manual transmission.

Need the ECU as well? The same application is also available as: Elite 1500 ECU kit (HT-150939).

What You'll Feel

  • VTEC engagement you set, by RPM, load and temperature
  • A boosted B-series with sequential injection, real MAP load sensing and logging, in a chassis that never had any of it
  • Factory connectors that click home instead of a loom you have to rebuild
  • A stock harness you can return to at any time

Features

  • Plug 'n' play adaptor with the Honda OBD-I B-Series factory ECU connector layout
  • Suits Haltech Elite 1000/1500 ECUs
  • No cutting or splicing of the factory harness, fully reversible
  • Includes an M14 x 1.5 air temp sensor with plug and pins, so the ECU sees real intake temperature from day one
  • Auxiliary I/O 16-pin Tyco plug and pins for extra sensors and outputs (wideband, fuel and oil pressure, flex fuel)
  • Haltech quick start guide walks through the fit
  • Backed by the Haltech limited warranty

The Details

Part number HT-140840. Plug 'n' Play replacement of the factory ECU for Honda OBD-I B-Series 92-95 Civic, Integra and Prelude. 90-95 Accord. Manual transmission only. Unsure whether your car matches? Send us the VIN or a photo of the factory ECU plug before ordering and we will confirm.

Kit Includes

  • 1x Injection molded plastic plug 'n' play adaptor harness
  • 1x M14 x 1.5 air temp sensor with matching plug and pins
  • 1x Auxiliary I/O 16 Pin Tyco plug and pins

Applications

  • Honda OBD-I B-Series, B-series
  • 1992-1995 Honda Civic
  • 1992-1995 Acura Integra
  • 1992-1995 Honda Prelude
  • 1990-1995 Honda Accord
  • Requires a Haltech Elite 1000/1500 ECU (sold separately)

Tuned By Shawn is a Platinum Haltech Dealer with in-house wiring and remote tuning. If this is part of a larger build, ask and we will spec the full parts list.
