Haltech Nexus R5 LSx DBW Terminated Harness - DBW ready Injector Connector: EV6 (HT-186205)

Haltech Nexus R5 LSx DBW Terminated Harness - DBW ready is the fastest way to wire this engine properly: labelled, pre-terminated wiring built for the application, so the engine side of a swap or race build is done in hours instead of days. Vehicles equipped with GM LSx engines with DBW throttle needing a vehicle rewire with PDM functionality. Pre-wired to connect directly to OEM 7 Pin Coil Harness Connector.

Why It Matters

Wiring is where builds stall and where gremlins are born. A terminated harness means correct pinouts the first time, labelled circuits that make diagnosis simple, and no splices to suspect later. An LS swap wired and controlled properly starts on the first key turn, idles like stock, and takes power adders without drama.

Features

• Engine management, PDM, data logger, and dual channel wideband controller in one device
• 4 x 25A push-pull PWM outputs and 12 x 8A high side outputs
• 18 peak and hold injector drivers and 12 ignition outputs
• 4 x 8A h-bridge outputs for electronic throttle
• 23 analogue inputs with DBW redundancy
• 2 onboard wideband controllers, 3 CAN ports

The Details

• SKU: HT-186205

Applications

Vehicles equipped with GM LSx engines with DBW throttle needing a vehicle rewire with PDM functionality. Pre-wired to connect directly to OEM 7 Pin Coil Harness Connector. Built for GM LS applications. Unsure about fitment for your build? Send us your engine and chassis details before ordering and we will confirm compatibility.

Tuned By Shawn is a Platinum Haltech Dealer. Remote tuning sessions over live Zoom are available, so once the hardware is installed we can calibrate it on your injectors, your fuel, and your combination without the car leaving your garage.
