ORB Tee FFF

Three o-ring boss ports in one machined body: the junction for hardware that speaks ORB.

The Finish Line Factory ORB Tee FFF handles fluid junctions for most automotive fuels, oils, and coolants, with three female ORB ports in 4AN, 6AN, 8AN, 10AN, 12AN, 16AN, 20AN so o-ring-sealed hardware plumbs straight in. Precision made, and shaped for the systems that already committed to this thread standard.

Benefits

• The junction bolts together from parts on the shelf instead of a fabrication session
• O-rings seat with smooth, modest torque at all three ports
• Branch fittings aim independently, so routing stays sane
• One machined body replaces a cluster of improvised adapters

Features

• Three female ORB ports, sizes 4AN, 6AN, 8AN, 10AN, 12AN, 16AN, 20AN
• O-ring boss sealing at every port
• Compatible with most automotive fuels, oils, and coolants
• Tee configuration for feeds, returns, and sensor branches
• Sold as a single fitting

The Details

ORB junctions keep every seal an o-ring: modest torque, no sealant, and fittings that clock freely before final tightening because the seal happens on the face, not the thread. Inspect each o-ring at assembly and keep spares; FLF Viton O-Rings cover fuel and oil duty. A tee earns its keep at gauge taps, split returns, vent junctions, and anywhere one line becomes two; size the branches for their real flow, not symmetry. Back up the body with a wrench at every assembly step so torque on one port never disturbs another.

Kit Includes

• 1x ORB Tee FFF (size per your selection)

Applications

• Port sizes: 4AN, 6AN, 8AN, 10AN, 12AN, 16AN, 20AN
• Common uses: fuel rail junctions, regulator returns, o-ring-sealed sensor manifolds
• Compatible with most automotive fuels, oils, and coolants
