Fuel Pump Bracket

A Bosch 044 hanging off its hose ends is a fuel leak on layaway.

External fuel pumps are dense little masses that vibrate for a living. The Finish Line Factory Fuel Pump Bracket anchors one properly: a secure clamping design with a rubber gasket holding the pump in place, sized for 61mm ID bodies like the Bosch 044. Pumps mounted like the fuel system depends on it, because it does.

Benefits

• Pump vibration dies in the rubber instead of ringing through the chassis
• The clamp wraps the body evenly, no hose-clamp dents
• Fittings connect to a pump that holds still
• The buzz of pump duty fades to a hum through the isolation

Features

• Secure clamping design with rubber gasket isolation
• Fits 61mm ID pump bodies (Bosch 044 pattern)
• Common external EFI pump compatibility
• Anchors pumps to chassis or panel
• Sold individually

The Details

External pumps ask two things of a mount: hold firm and isolate. Rigid mounting without rubber transmits the pump's drone into the chassis as a soundtrack; soft mounting without clamp lets the mass work its fittings loose. This clamp answers both, wrapping the 61mm body with even pressure over its rubber gasket. Mount low and near the tank, since pumps push far better than they pull, keep wiring supported off the fittings, and torque clamp hardware to snug rather than crush; the rubber does its job under compression, not strangulation.

Kit Includes

• 1x Fuel Pump Bracket (size per your selection)

Applications

• Fits 61mm ID pump bodies
• Common uses: Bosch 044-pattern external pumps, surge tank outputs, trunk and underbody pump mounting
• Pairs with FLF check valves and fuel plumbing
