Crimp-On Swivel Hose End (Braided PTFE) - 90 Degree AN

A hose forced into a right angle at its own collar is a slow-motion failure.

Crimped PTFE is the no-excuses fuel line: the liner shrugs off E85 and the swaged sleeve never backs off. The Finish Line Factory Crimp-On Swivel Hose End (Braided PTFE) - 90 Degree AN permanently crimps onto nylon braided PTFE hose with a swiveling female AN nut and o-rings selected for racing fuels, in 4AN, 6AN, 8AN, 10AN, 12AN. The 90 degree outlet sets the route before the crimper ever closes. As close to factory-line permanence as a home-built system gets.

Benefits

• Lines tuck flat against tanks and rails instead of looping out for clearance
• Nothing to re-torque, re-check, or worry about after heat cycles
• The swivel nut still spins for flare alignment after crimping
• Slimmer profile than a cutter-style PTFE end in tight quarters
• The finished crimp is a single rigid unit, zero collar wiggle

Features

• Crimp-on design purpose-built for nylon braided PTFE hose
• Female AN swivel nut sealing on the 37 degree flare
• 90 Degree outlet angle
• Sizes: 4AN, 6AN, 8AN, 10AN, 12AN
• O-rings selected for racing fuels including E85, plus oil, water, and air
• Rebuildable with FLF replacement PTFE crimp sleeves

The Details

Building the full right angle into the fitting protects the hose liner, because no braided hose survives being bent 90 degrees at the collar; the sweep inside the fitting carries the turn instead. Pairing PTFE liner with a crimped sleeve stacks the two most durable choices in hose plumbing: chemistry-proof wall, mechanically permanent retention. The sleeve cold-forms around hose and nipple to a published diameter, so assembly is a crimper-and-calipers job rather than a wrench job; cut square, seat the hose to full depth, crimp, measure. The AN connection remains a dry 37 degree flare, no sealant ever. When a hose eventually retires, the machined body rebuilds with a fresh replacement sleeve. Choose crimped PTFE where the fluid is aggressive and the line must be install-and-forget; choose the reusable PTFE swivel ends instead when routes are still evolving and rebuilds will be frequent.

Kit Includes

• 1x Crimp-On Swivel Hose End (Braided PTFE) - 90 Degree AN (size per your selection)

Applications

• Sizes: 4AN, 6AN, 8AN, 10AN, 12AN
• Mates to any male AN flare fitting in the matching size
• Common uses: E85 and methanol-blend fuel systems, permanent fuel feed and return lines, high-temperature oil runs, vapor and vent lines
• For FLF PTFE Hose w/ Braided Nylon; not for rubber-lined hose
